A cement spreader with controllable discharge function, including a vehicle body, wherein a hopper is placed on the top outer wall of the vehicle body, and a control module is fixed on one side of the outer wall of the hopper through bolts. The control module is internally equipped with a speed sensor and display screen, and the speed sensor is connected to the vehicle control system of the vehicle body 1 through a bus. An alarm is fixed on one side of the outer wall of the hopper through bolts, The switch control end of the alarm is electrically connected to the control module, where the volume density or mass density parameters of the material to be distributed are input in advance. During operation, the speed sensor detects the driving speed of the vehicle body 1 in real time and transmits a signal to the control module. When the speed exceeds or falls below the set value, the control module 6 is electrically connected to the control alarm 14 to send an alarm, warning people, The control module performs data analysis and transmits the data to the display screen for real-time viewing by people.

粉料撒布車

Powder spreader

為了對需鋪設的路面進行碾壓；所述車體1的底部外壁通過螺栓固定有固定座，固定座的兩側內壁通過轉軸轉動連接兩個滾筒，車體的一側外壁通過螺栓固定有出料箱，料倉的底部外壁通過螺栓固定有第一電動伸縮板，第一電動伸縮板的開關控制端與控制模塊電性連接，車輛行駛過程中，兩個滾筒隨著車輛前進在固定座2內轉動，對需鋪設的路面進行碾壓，控制模塊電性連接控制第一電動伸縮板的開關，使得物料通過出料箱進行出料，便于撒布作業。

To compact the road surface to be laid; The bottom outer wall of the vehicle body 1 is fixed with a fixed seat through bolts, and the inner walls on both sides of the fixed seat are connected to two rollers through rotating shafts. One side of the outer wall of the vehicle body is fixed with a discharge box through bolts, and the bottom outer wall of the material bin is fixed with a first electric expansion plate through bolts. The switch control end of the first electric expansion plate is electrically connected to the control module. During the vehicle's driving process, the two rollers rotate in the fixed seat 2 as the vehicle moves forward, Rolling the road surface to be laid, the control module is electrically connected to control the switch of the first electric expansion plate, allowing the material to be discharged through the discharge box, facilitating the spreading operation.

為了避免加料過程中粉塵飛揚；所述料倉的頂部外壁通過螺栓固定有粉料箱，粉料箱的頂部外壁通過螺栓固定有固定板，固定板的一側外壁通過螺栓固定有彈簧，粉料箱的兩側內壁通過螺栓固定有轉動軸，轉動軸的圓周外壁套接有擋板，彈簧的另一端通過螺栓與擋板的頂部外壁相連接，向粉料箱內添加粉料時，粉料下沉在擋板上，彈簧彈性變形拉伸，擋板的一端受力下滑，擋板通過轉動軸使得粉料箱打開一定角度進行加料，添加粉料完畢后，彈簧收縮，使得擋板一端向上回位，從而對粉料箱13進行閉合，有效避免加料過程中，粉塵飛揚引起大氣污染。

To avoid dust flying during the feeding process; The top outer wall of the material bin is fixed with a powder box through bolts, and the top outer wall of the powder box is fixed with a fixed plate through bolts. One side of the outer wall of the fixed plate is fixed with a spring through bolts, and the inner walls of both sides of the powder box are fixed with rotating shafts through bolts. The circumferential outer wall of the rotating shaft is connected with a baffle, and the other end of the spring is connected to the top outer wall of the baffle through bolts. When adding powder to the powder box, the powder sinks onto the baffle, The spring deforms and stretches, causing one end of the baffle to slide under force. The baffle rotates the shaft to open the powder box at a certain angle for feeding. After adding powder, the spring contracts, causing one end of the baffle to return to its original position, thus closing the powder box 13, effectively avoiding dust flying and causing atmospheric pollution during the feeding process.

為了便于控制粉料的輸入量所述粉料箱的一側外壁開設有安裝槽，料倉的頂部外壁通過螺栓固定有第二電動伸縮板，第二電動伸縮板的開關控制端與控制模塊6電性連接，第二電動伸縮板的一端與安裝槽相匹配，且第二電動伸縮板的頂部外壁通過螺栓固定有稱重傳感器，稱重傳感器18的型號為pts124-133g，稱重傳感器的信號輸出端與控制模電性連接，向粉料箱內添加粉料過程中，稱重傳感器實時檢測第二電動伸縮板上的重量變化，當達到設定值時，傳遞信號給控制模塊，控制模塊6電性連接控制第二電動伸縮板開關，使得粉料箱內的物料下滑至料倉內，嚴格控制粉料的輸入量，確保后期的水泥質量。

In order to facilitate the control of the input amount of powder, an installation groove is set on one side of the outer wall of the powder box. The top outer wall of the material bin is fixed with a second electric expansion plate through bolts, and the switch control end of the second electric expansion plate is electrically connected to the control module 6. One end of the second electric expansion plate matches the installation groove, and the top outer wall of the second electric expansion plate is fixed with a weighing sensor through bolts. The model of the weighing sensor 18 is PTS124-133g, The signal output end of the weighing sensor is electrically connected to the control module. During the process of adding powder to the powder box, the weighing sensor detects the weight change on the second electric expansion plate in real-time. When the set value is reached, the signal is transmitted to the control module. Control module 6 is electrically connected to control the switch of the second electric expansion plate, causing the material in the powder box to slide into the silo. The input amount of powder is strictly controlled to ensure the later cement quality.

為了便于向料倉內添加水；所述料倉的頂部外壁通過螺栓固定有水箱，水箱的圓周外壁通過螺栓固定有輸水管，輸水管的圓周外壁通過螺栓固定有電動閥門，電動閥門的開關控制端與控制模塊6電性連接，料倉的一側外壁通過螺栓固定有透視窗5，透視窗的一側外壁粘接有刻度線，打開電動閥門，水箱通過輸水管向料倉內添加水，期間，通過透視窗可以清晰了解水箱內的物料使用情況。

To facilitate the addition of water to the silo; The top outer wall of the silo is fixed with a water tank through bolts, the circumferential outer wall of the water tank is fixed with a water delivery pipe through bolts, and the circumferential outer wall of the water delivery pipe is fixed with an electric valve through bolts. The switch control end of the electric valve is electrically connected to the control module 6. One side of the outer wall of the silo is fixed with a perspective window 5 through bolts, and one side of the outer wall of the perspective window is bonded with a scale line. Open the electric valve, and the water tank adds water to the silo through the water delivery pipe, During this period, the use of materials in the water tank can be clearly understood through the perspective window.
